Quadlogic Residential Solutions

Complete Submetering Solutions for New or Existing Construction

Bill tenants while reducing energy consumption. Quadlogic submeters  easily integrate with your existing building and financial systems.

Residential Meters

QBrick 1

Single-Point Smart Meter

Features

  • Monitors a single 3-phase circuit. Daisy chain up to 247 Q-Family meters to a single meter data hub for local and remote access to meter data.

  • Communicates Modbus RTU over standard 2-wire RS485 and optional Wireless Radio communication.

  • Meets or exceeds all requirements of ANSI C12.20.

  • Dimensions - L × H × D = 261 mm×125 mm×71 mm

QBrick 4

Multi-Tenant Smart Meter

Features

  • Monitors four 3-phase circuits. Daisy chain up to 247 Q-Family meters to a single meter data hub for local and remote access to meter data.

  • Communicates Modbus RTU over standard 2-wire RS485 and optional Wireless Radio communication.

  • Meets or exceeds all requirements of ANSI C12.20.

  • Dimensions - L × H × D = 261 mm×125 mm×71 mm

QBrick 6

Multi-Tenant Smart Meter

Features

  • Monitors six 2-phase circuits. Daisy chain up to 247 Q-Family meters to a single meter data hub for local and remote access to meter data.

  • Communicates Modbus RTU over standard 2-wire RS485 and optional Wireless Radio communication.

  • Meets all requirements of ANSI C12.20

  • Dimensions - L × H × D = 261 mm×125 mm×71 mm

QBrick Display Unit

Remote Display

Features

  • The QBrick Display Unit (D-Unit), is a remote display for up to 16 QBrick meters (any combination of Qbrick 1, 4, or 6).

  • The D-Unit interfaces to QBrick meters with a hardwired Modbus RS485 connection to the meters' dedicated D-Unit comm port.

  • A customer may use a D-Unit to view meter configurations and energy readings.

  • The D-Unit is a read-only device that is not capable of making changes to the QBrick meter configurations or readings.

QTao

Universal Data Gateway

Features

  • Collects data through Modbus, Pulse and M-Bus protocols

  • BACnet interface for 3rd-party Building Management Software

  • Local Wi-Fi hotspot for troubleshooting with capability to upgrade remotely

  • Ability to access data remotely using our web portal QView

Additional Details

Qlic E-Meter 400

Multi-Channel Energy Meter

Features

  • Uses Modbus RTU and is Modbus TCP and BACnet Compatible

  • Meets ASHRAE 90.1 -2016 requirements

  • Field Programmable for (4) 3-Phase Meters, (4) 2-Phase Meters and (12) 1-Phase Meters

  • Dimensions: 5.2”H x 3.4”L x 1.8”D

Additional Details

This is a Non-Revenue Grade meter.

Brochure

Wiring Diagrams

S-10T

In-unit Submeter

Features

  • Compact, Unobtrusive Design

  • Integrated Power Line Communications

  • Surface Mount Dimensions: 3.4” H X 6.5” W X 1.6” D

  • 0.5 Class per ANSI C12.20-2010

Additional Details
